MAX CPM-100HG5

MAX CPM-100HG5
MAX CPM-100HG5 - Image 2
MAX CPM-100HG5 - Image 3
MAX CPM-100HG5 - Image 4

4 inch Wide Sign and Label Printing & Cutting Machine with process color capability

MAX CPM-100HG5 4 inch wide sign and label printing and cutting machine. The CPM-100HG5 combines thermal print and vinyl-cutting technology, together with our tried and tested software, to product multiple spot, or full-color outputs.

Applications

ANSI and OSHA Agency Required Signage

Health & Safety Signs

Product & Asset Labelling

Visual Management Signs

Pipe Marking / GHS Labels

5S / Kaizen / Kanban Labels

Wire and Cable Marking

Custom Labels

Download Brochure
  • FEATURES
  • SPECIFICATIONS
  • CONSUMABLES
FEATURES
SIGNS AND LABELS ON DEMAND

You can create your own signs and labels wherever and whenever you want them with MAX CPM system

INTEGRATED PLOTTER/CUTTER

Cuts any shape and size to suit your signs and labeling needs

REDUCE COSTS

Print custom labels and signs in-house with the MAX CPM system. You can save money by eliminating waste and decreasing purchasing costs.

LARGE TEMPLATE AND SYMBOL LIBRARY

MAX Bepop PC-EX software has over 1,400 symbols and templates

INCLUDE PHOTOS AND IMAGES

MAX 4 color process technology, using CMYK ribbons, allows you to import and print any photos and logos on the 4 inch wide white tape roll.

TECHNOLOGY FRIENDLY

Prints UPC, QR codes and much more

CSV DATABASE CONNECTION

Variable information from your database saved in CSV format, can be linked directly to your label designs

HIGH DEFINITION

Prints 400 DPI for clarity of smallest font size and clearer photo images

SPECIFICATIONS
DIMENSIONS 12.6″(H) x 13.0″(W) x 12.6″(L)
WEIGHT 19.8 lbs
PRINT TECHNOLOGY Thermal Transfer
COLOR PRINTING CAPABILITY Multi-Color
PRINT RESOLUTION 400 dpi
PRINTING SPEED 1 inch/sec.
CUTTING SPEED 4.7 inch/sec.
CUTTING FUNCTION Free-cut (Shapes, Letters, Bordering, etc.)
MAXIMUM OUTPUT RANGE 4 inch x 78.7 inch
MAXIMUM PRINT WIDTH 4 inch
CONNECTIVITY USB2.0 Full Speed
OPERATING TEMPERATURE 50-95°F (10-35℃)
OPERATING HUMIDITY 35-80%, non-condensing
POWER SUPPLY VOLTAGE AC 100-240V
CONSUMABLES
Description Label / Ribbon size Color Material Package
PREMIUM TAPE ROLL SL-S111GN BLACK PREMIUM TAPE ROLL 4 in W x 49 ft L BLACK GLOSSY PVC 1roll/box
PREMIUM TAPE ROLL SL-S112GN WHITE PREMIUM TAPE ROLL 4 in W x 49 ft L WHITE GLOSSY PVC 1roll/box
PREMIUM TAPE ROLL SL-S113GN RED PREMIUM TAPE ROLL 4 in W x 49 ft L RED GLOSSY PVC 1roll/box
PREMIUM TAPE ROLL SL-S114GN BLUE PREMIUM TAPE ROLL 4 in W x 49 ft L BLUE GLOSSY PVC 1roll/box
PREMIUM TAPE ROLL SL-S115GN YELLOW PREMIUM TAPE ROLL 4 in W x 49 ft L YELLOW GLOSSY PVC 1roll/box
PREMIUM TAPE ROLL SL-S116GN GREEN PREMIUM TAPE ROLL 4 in W x 49 ft L GREEN GLOSSY PVC 1roll/box
PREMIUM TAPE ROLL SL-S118GN ORANGE PREMIUM TAPE ROLL 4 in W x 49 ft L ORANGE GLOSSY PVC 1roll/box
PREMIUM TAPE ROLL SL-S110GN CLEAR PREMIUM TAPE ROLL 4 in W x 49 ft L CLEAR GLOSSY PVC 1roll/box
PREMIUM TAPE ROLL SL-S126GN BROWN PREMIUM TAPE ROLL 4 in W x 49 ft L BROWN GLOSSY PVC 1roll/box
PREMIUM TAPE ROLL SL-S108GN SILVER PREMIUM TAPE ROLL 4 in W x 49 ft L SILVER GLOSSY PVC 1roll/box
PREMIUM TAPE ROLL SL-S109GN GOLD PREMIUM TAPE ROLL 4 in W x 49 ft L GOLD GLOSSY PVC 1roll/box
SPECIAL TAPE ROLL SL-S163N PET HL SILVER TAPE ROLL 4 in W x 49 ft L HAIR-LINED SILVER POLYESTER 1roll/box
SPECIAL TAPE ROLL SL-S164N PET HL GOLD TAPE ROLL 4 in W x 49 ft L HAIR-LINED GOLD POLYESTER 1roll/box
SPECIAL TAPE ROLL SL-S153N PET WHITE TAPE ROLL 4 in W x 33 ft L WHITE POLYESTER 2rolls/box
SPECIAL TAPE ROLL SL-S154N PET MAT SILVER TAPE ROLL 4 in W x 33 ft L MAT SILVER POLYESTER 2rolls/box
SPECIAL TAPE ROLL SL-S141N REFLECTIVE WHITE TAPE ROLL 4 in W x 33 ft L WHITE REFLECTIVE 2rolls/box
SPECIAL TAPE ROLL SL-S100AP APPLICATION SHEET 4 in W x 65 ft L 2rolls/box
SPECIAL TAPE ROLL SL-L100 FLOOR LAMINATE (80 micron) 4 in W x 98 ft L 1roll/box
INK RIBBON SL-R101T BLACK-C RIBBON 4 in W x 180 ft L BLACK RESIN 1pc
INK RIBBON SL-R122TH SUPER WHITE RIBBON 4 in W x 180 ft L WHITE RESIN 1pc
INK RIBBON SL-R103T RED-C RIBBON 4 in W x 180 ft L RED RESIN 1pc
INK RIBBON SL-R104T BLUE-C RIBBON 4 in W x 180 ft L BLUE RESIN 1pc
INK RIBBON SL-R105T DARK BLUE-C RIBBON 4 in W x 180 ft L DARK BLUE RESIN 1pc
INK RIBBON SL-R106T DARK GREEN RIBBON 4 in W x 180 ft L DARK GREEN RESIN 1pc
INK RIBBON SL-R107T GREEN-C RIBBON 4 in W x 180 ft L GREEN RESIN 1pc
INK RIBBON SL-R108T YELLOW-C RIBBON 4 in W x 180 ft L YELLOW RESIN 1pc
INK RIBBON SL-R112T ORANGE-C RIBBON 4 in W x 180 ft L ORANGE RESIN 1pc
INK RIBBON SL-R115T CMYK-C RIBBON 4 in W x 180 ft L PROCESS CYAN RESIN 1pc
INK RIBBON SL-R116T CMYK-M RIBBON 4 in W x 180 ft L PROCESS MAGENTA RESIN 1pc
INK RIBBON SL-R117T CMYK-Y RIBBON 4 in W x 180 ft L PROCESS YELLOW RESIN 1pc
INK RIBBON SL-R118T CMYK-K RIBBON 4 in W x 180 ft L PROCESS BLACK RESIN 1pc
ACCESSORIES CM-B20E BLADE 1pc
