LX4000e Color Label Printer
Print Speeds – With a maximum print speed of up to 114 mm (4.5”) per second, your labels will be produced quickly and efficiently
Best Print Quality – 4800 dpi full-colour printing, 16.7 million colours
Individual Ink Tanks – The highly advanced ink technology used by LX4000e is unique in the business. It has a reusable, pre-primed printhead that's fed through tubing from three separate large (3 x 60 ml) CMY ink tanks
Sturdy Metal Enclosure – The LX4000e comes with a powder coated metal enclosure which had been certified for many years in areas with higher safety regulations. Especially suitable for use in mechanical and plant engineering or when electromagnetic screening (EMC) is required
Cutter – Equipped with a built-in label cutter (pizza-wheel style)
Connection – USB 2.0 and Wired Ethernet for network connection
Print Width – up to 210 mm wide
Specifications
| Print Method | Thermal inkjet with dye or pigment ink |
| Print Resolution | 600 x 1200 dpi native; up to 1200 x 4800 dpi |
| Droplet size | 4 picolitre |
| Print Speeds | Up to 114 mm (4.5”) per second |
| Inks | Separate Cyan, Magenta and Yellow Ink Tanks, process black |
| Printhead | User replaceable, multi-use printhead |
| Colours | 16.7 million |
| Colour Matching | ICC colour profiles included; ability to add custom ICC colour profiles for other media types |
| Print Width | 13 mm - 210 mm (0.5” - 8.25”) |
| Media Width | 38 mm - 212 mm (1.5” - 8.375”) |
| Print Length | 13 mm - 1524 mm (0.5” - 60”) |
| Media Types | Roll-fed pressure-sensitive labels, roll-fed tags, fan-fold labels or tags |
| Media Sensing | Moveable see-through sensor for die-cut labels; reflective sensor for labels and tags with black mark (bottom); can use continuous and pre-printed labels and tags |
| Media Feed | Internal or external |
| Supply Roll | 152 mm (6”) maximum outer diameter on 76 mm (3”) core |
| Cutter | Built-in “pizza-wheel” style label cutter |
| Ink Level Warning | Calculates actual number of prints remaining based upon ink usage of graphics being printed. |
| Operating Systems | Windows 8 and higher | Mac OS X 10.13 and higher |
| Data Interface/ Connections | USB 2.0, wired Ethernet (Windows only) |
| Label Design Software | NiceLabel Free DTM Edition and BarTender UltraLite DTM Edition (Windows) | Belight Swift Publisher 5 (Mac)* |
| Power Requirements | 100 V - 240 V AC (50/60 Hz), 12 V DC, 5.0 A |
| Certifications | UL, UL-C, CE, FCC Class A, RoHS, UKCA |
| Weight | 16.6 kg |
| Dimensions (WxHxD) | 438 mm x 231 mm x 438 mm |
| Operating Temperature | 10 °C - 35 °C |
| Operating Humidity | 10 % - 60 % RH (non-condensing) |
| Available Versions | LX4000e with dye-based ink (074435) LX4000e with pigment ink (074436) |
| What’s in the Box | LX4000e Color Label Printer, a set of CMY ink tanks, a pre-primed printhead, one 6x4” DTM Paper Semi Gloss (dye) or DTM Paper Matte (pigment) starter roll, USB 2.0 cable, EU power cord and instructions** |
| Warranty | 36 months (after product registration, for devices purchased in EU/EFTA countries and UK) |
| Manufacturer | Primera Technology, Inc. |
