Laser Engraving System — GCC E200S
To engrave and mark on materials like metal, plastic, and laser hot foil for bonding. Designed to remove hazardous fumes and dust during laser processing.
12-month warranty on labour and non-wet parts, on every brand we carry.
- Work Area
- 510 x 330 mm (20 x 12.9 in.)
- Maximum Part Size (WxLxH)
- 520 x 340 x 20 mm (20.4 x 13.4 x 0.78 in.) (with grid…
- CCD Camera
- Standard, accurate within 4mm (0.16 in.)
- Working table
- Standard grid cutting table
Specifications
23 specifications, as published by LabelGraff for the GCC E200S.
- Work Area
- 510 x 330 mm (20 x 12.9 in.)
- Maximum Part Size (WxLxH)
- 520 x 340 x 20 mm (20.4 x 13.4 x 0.78 in.) (with grid cutting table) · 505 x 340 x 76 mm (19.8 x 13.4 x 2.99 in.) (remove grid cutting table)
- Maximum Working Speed
- 20 IPS
- Maximum Cutting Thickness
- 10mm
- Speed Control
- Adjustable from 0.1~100% (Up to 5 color-linked speed settings per job)
- DPI
- Available 250,380,500,760,1000
- Computer interface
- Full-speed USB 2.0 port, 10 Base-T Ethernet
- Compatible Operating systems
- MS Windows (SmartJOB/Printer driver), Mac OS (SmartJOB)
- Control Panel
- 7”touch screen
- Connection
- WiFi, Ethernet, USB
- Power Control
- Adjustable from 0~100% (Up to 5 color-linked power settings per job)
- Electrical
- 100-240VAC, 50-60Hz Auto Switching, Max. 15A
- Dimensions
- 915 x 780 x 300 mm (36 x 30.7 x 11.8 in. )
- CCD Camera
- Standard, accurate within 4mm (0.16 in.)
- Working table
- Standard grid cutting table
- Laser Source
- 40W Sealed CO2 laser
- Drive
- Closed-loop DC Servo Control
- Focus Lens
- Standard 1.5”
- Water Chiller
- Standard
- Air Compressor
- Built-in, available for external high performance air compressor(Option)
- Blue Laser
- 10W 450 nm (Option)
- Safety
- Class 1 Laser Product Complies with EN60825-1 · Class 2 Laser Product Complies with CDRH · Class 4 Laser Product Complies with Blue Laser (Option)
- Fum Extraction System
- External exhaust system with minimum flow rate 300 m3/h (10594 ft3/h) is required, 2,500PA negative pressure (Pure-Air PA-300 @ 4" exhaust port)
