Eddie Edible Ink Printer

Discover the versatile Eddie Edible Ink Printer. High-resolution printing up to 1200 x 1200 dpi. Fast, efficient, and perfect for edible creations.

Print Method: Thermal inkjet with edible ink

Max. Print Speed: 5 – 6 items per minute,

Varies by item size and print

Media Thickness: Up to 25mm

Print Resolution: 1200 x 1200 dpi

Download Brochure

Specifications Eddie Edible Ink Printer

Print Method:	Thermal inkjet with edible ink
Print Resolution:	1200 x 1200 dpi native; up to 1200 x 4800 dpi
Print Speeds:	Varies by item size and print (e.g. for objects with Ø 89 mm 5-6 pcs./minute)
Inks:	Single high capacity CMY ink cartridge, process black
Dyes Contained in the CMY Cartridge:	Cyan: Blue #1 – Brilliant Blue FCF (E133) Magenta: Carmoisine – Azorubin (E122) Yellow: Yellow #5 – Tartrazin (E102), Yellow #6 – Sunset Yellow FCF (E110)
Printhead:	Included in cartridge
Colours:	16.7 million
Print Width:	up to 120 mm
Item Width:	Carousel: 89 – 105 mm (with spacer 63.5 – 86.68 mm) DTM Carousel Trays: 0 – 89 mm Platform Kit: 0 – 120 mm DTM Trays: 0 – 120 mm
Item Height/Thickness:	Carousel: 3 – 19 mm DTM Carousel Trays: 3 – 19 mm Platform Kit: 30 – 60 mm (use raiser for Carousel or DTM Trays) DTM Trays: 2 – 27 mm
Feeding Mechanism:	Platform Kit & DTM Trays (manual): The feeding arm feeds the printed objects into the printer, which automatically adjusts the height, prints the objects and then presents them. Carousel & DTM Carousel Trays (automatic): The objects are conveyed from the carousel plate into the printer and placed back on the plate when printing is finished.
Ink Level Warning:	Calculates actual number of prints remaining based upon ink usage of graphics being printed.
Indicator Lights:	Power, Ink
Controls:	Load/Unload, Pause
Operating Systems:	Windows 7 – 11 Mac OS X 10.11 – macOS 12
Data Interface/Connections:	USB 2.0
Design Software:	BarTender UltraLite and NiceLabel Free DTM Version (Windows) Belight Swift Publisher (Mac) Can also be used with most other popular label design & graphics programs.
Power Requirements:	100-240 V AC (50/60 Hz), 36 W or 12 V DC, 3 A
Certifications:	UL, UL-C, FCC Class A, NSF/ANSI Standard 18 Manual Food and Beverage Equipment. 21CFR: US Code of Federal Regulations, Title 21 – US FDA EU 231/2012: Regulation (EU) No 231/2012 laying down specifications for food additives
Weight:	Total weight 11.3 kg Printer: 8.5 kg Carousel and base: 2.8 kg
Dimensions (WxHxD):	Total: 406 mm x 181 mm x 792 mm Printer: 317 mm x 181 mm x 474 mm Carousel: 406 mm x 72 mm x 421 mm
Operating Temperature:	10 °C to 35 °C
Operating Humidity:	10 % to 60 % RH (non-condensing)
What’s in the Box:	Eddie Edible Ink Printer, edible ink cartridge (053499), carousel (base + plate), USB 2.0 cable, EU power cord and instructions Design Software and printer driver can be downloaded from the DTM Print website.
Recommended Accessoires:	Different trays and spacers are available for both automatic and manual feed. These allow printing on any objects within the mentioned specifications.
Warranty:	36 months (after product registration for devices, purchased in EU, EFTA countries and UK)
Manufacturer:	Primera Technology, Inc.

CAROUSEL TRAY

DOWNLOAD TEMPLATE

053259DTM-CT0000

Version 1 Base Grid, 10 - 80 mm markings (10 mm steps) Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

CAROUSEL TRAY

DOWNLOAD TEMPLATE

053259DTM-CT0000

Version 2 Base with silicon layer 4 Marking circles, ø 20 - 80 mm (20 mm steps) Example: Wafers, Macaron shell, Biscuits, Cookies Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

CAROUSEL TRAY

DOWNLOAD TEMPLATE

053259DTM-CT0001

3 Circles, ø 42 mm Example: Small Biscuits, Macaron Shell Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

CAROUSEL TRAY

DOWNLOAD TEMPLATE

053259DTM-CT0002

8 Squares, 25 x 25 mm Example: Marshmallows Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

CAROUSEL TRAY

DOWNLOAD TEMPLATE

053259DTM-CT0003

3 Circles, ø 35 mm Example: Small Cookies, Marshmallows, Bonbons Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

CAROUSEL TRAY

DOWNLOAD TEMPLATE

053259DTM-CT0004

Circle, ø 58 mm Example: Biscuits, Cookies, Macaron Shell Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

CAROUSEL TRAY

DOWNLOAD TEMPLATE

053259DTM-CT0005

10 Ovals, 19 x 32 mm Example: Jelly Beans, Bonbons, Chocolate Beans Can be used together with Tray CT0006 Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

CAROUSEL TRAY

DOWNLOAD TEMPLATE

053259DTM-CT0006

10 Ovals, 15 x 25 mm Example: Jelly Beans, Bonbons, Chocolate Beans Can be used together with Tray CT0005 Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

CAROUSEL TRAY

DOWNLOAD TEMPLATE

053259DTM-CT0007

Rectangle, 45 x 90 mm Example: Cookies, Biscuits, Chocolate Bar Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

CAROUSEL TRAY

DOWNLOAD TEMPLATE

053259DTM-CT0008

3 Circles, ø 47 mm Example: Biscuits, Macaron Shell, Cookies Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

CAROUSEL TRAY

DOWNLOAD TEMPLATE

053259DTM-CT0009

Circle, ø 60 mm Example: Biscuits, Macaron Shell, Cookies Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

CAROUSEL TRAY

DOWNLOAD TEMPLATE

053259DTM-CT0010

Circle, ø 68 mm Example: Biscuits, Macaron Shell, Cookies Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

CAROUSEL TRAY

DOWNLOAD TEMPLATE

053259DTM-CT0011

4 Squares, 30 x 30 mm Example: Marshmallows Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

CAROUSEL TRAY

DOWNLOAD TEMPLATE

053259DTM-CT0012

2 Circles, ø 46 - 50 mm Example: Biscuits, Macaron Shell, Cookies This is a combination of two Trays Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

CAROUSEL TRAY

DOWNLOAD TEMPLATE

053259DTM-CT0013

3 Circles, ø 40 mm Example: Biscuits, Macaron Shell, Cookies Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

CAROUSEL TRAY

DOWNLOAD TEMPLATE

053259DTM-CT0014

6 Circles, ø 30 mm Example: Chocolates, Mints Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

CAROUSEL TRAY

DOWNLOAD TEMPLATE

053259DTM-CT5002

3 Star5, 48 mm Example: Cinnamon Star Cookies Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

MANUAL TRAY

DOWNLOAD TEMPLATE

053259DTM-M0001

Version 1 / Old Version (out of production) Base Grid, 5 x 5 mm Example: Wafers Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

MANUAL TRAY

DOWNLOAD TEMPLATE

053259DTM-M0001

Version 2 Base with silicon layer 4 Marking circles, ø 40 - 100 mm (20 mm steps) Example: Wafers, Macaron shell, Biscuits, Cookies Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

MANUAL TRAY

DOWNLOAD TEMPLATE

053259DTM-M0002

25 Circles, ø 15 mm Example: Chocolate Bonbons (size up to 20 mm) Can be used together with Tray M0003 Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

MANUAL TRAY

DOWNLOAD TEMPLATE

053259DTM-M0003

25 Circles, ø 20 mm Example: Chocolate Bonbons, Mints Can be used together with Tray M0002 Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

MANUAL TRAY

DOWNLOAD TEMPLATE

053259DTM-M0004

5 Circles, ø 35 mm Example: Macarons, Biscuits Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

MANUAL TRAY

DOWNLOAD TEMPLATE

053259DTM-M0005

64 Circles, ø 10 mm Example: M&Ms, Skittles, Bonbons (size up to 12 mm) Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

MANUAL TRAY

DOWNLOAD TEMPLATE

053259DTM-M0006

053259DTM-M0006 Example: mini Macarons, UFOs (size up to 40 mm) Can be used together with Tray M0007 Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

MANUAL TRAY

DOWNLOAD TEMPLATE

053259DTM-M0007

9 Circles, ø 30 mm Example: mini Macarons, UFOs (size up to 40 mm) Can be used together with Tray M0006 Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

MANUAL TRAY

DOWNLOAD TEMPLATE

053259DTM-M0008

Circle, ø 80 mm Example: Pastries, Cookies, Biscuits, Wafers Can be used together with Tray M0009 and M0010 Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

MANUAL TRAY

DOWNLOAD TEMPLATE

053259DTM-M0009

Circle, ø 90 mm Example: Pastries, Cookies, Biscuits, Wafers Can be used together with Tray M0008 and M0010 Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

MANUAL TRAY

DOWNLOAD TEMPLATE

053259DTM-M0010

Circle, ø 95 mm Example: Pastries, Cookies, Biscuits, Wafers Can be used together with Tray M0008 and M0009 Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

MANUAL TRAY

DOWNLOAD TEMPLATE

053259DTM-M0011

2 Rectangles, 55 x 75 mm Example: Biscuits, Wafers Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

MANUAL TRAY

DOWNLOAD TEMPLATE

053259DTM-M0012

4 Circles, ø 30 - 55 mm (5 mm steps) Example: Biscuits, Oreos, Macarons Size can be adjusted Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

MANUAL TRAY

DOWNLOAD TEMPLATE

053259DTM-M0013

5 Circles, ø 47 mm Example: Oreos, Biscuits Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

MANUAL TRAY

DOWNLOAD TEMPLATE

053259DTM-M0014

77 Rectangles, 7 x 12 mm (1/2)
77 Rectangles, 6 x 11 mm (2/2) Example: Tic-Tacs This is a combination of two Trays Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

MANUAL TRAY

DOWNLOAD TEMPLATE

053259DTM-M0015

4 Circles, ø 59 mm Example: Biscuits Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

MANUAL TRAY

DOWNLOAD TEMPLATE

053259DTM-M0016

4 Squares, 35 - 55 mm
(5 mm steps) Example: Biscuits Size can be adjusted Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

MANUAL TRAY

DOWNLOAD TEMPLATE

053259DTM-M0017

9 Squares, 30 x 30 mm Example: Candies, Mints, Gummies Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

MANUAL TRAY

DOWNLOAD TEMPLATE

053259DTM-M0018

Square, 60 - 100 mm
(10 mm steps) Example: Cookies, Biscuits Size can be adjusted Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

MANUAL TRAY

DOWNLOAD TEMPLATE

053259DTM-M0019

4 Ovals, 50 x 40 / 55 x 45 mm Example: Cookies, Biscuits Size can be adjusted Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

MANUAL TRAY

DOWNLOAD TEMPLATE

053259DTM-M0020/21

18 Ovals, 15 x 25 mm (M0020)
18 Ovals, 19 x 32 mm (M0021) Example: Mints, Pills, Candies This is a combination of two Trays Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

MANUAL TRAY

DOWNLOAD TEMPLATE

053259DTM-M0022

3 Circles, ø 60 mm Example: Biscuits, Cookies Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

MANUAL TRAY

DOWNLOAD TEMPLATE

053259DTM-M0023

5 Circles, ø 41 mm Example: Biscuits, Cookies, Macaron Shells Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

MANUAL TRAY

DOWNLOAD TEMPLATE

053259DTM-M0024

12 Rectangles, 33 x 23 mm Example: Small Biscuits, Marshmallows Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

MANUAL TRAY

DOWNLOAD TEMPLATE

053259DTM-M0025

12 Ovals, 33 x 21 mm Example: Bonbons, Mints Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

MANUAL TRAY

DOWNLOAD TEMPLATE

053259DTM-M0026

Circle, ø 115 mm Example: Biscuits, Cookies, Macaron Shells Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

MANUAL TRAY

DOWNLOAD TEMPLATE

053259DTM-M0027

4 Squares, 45 x 45 mm Example: Biscuits, Cookies Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

MANUAL TRAY

DOWNLOAD TEMPLATE

053259DTM-M0028

Rectangle, 70 x 80 mm Example: Biscuits, Cookies Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

MANUAL TRAY

DOWNLOAD TEMPLATE

053259DTM-M0029

Square, 50 - 70 - 90 mm
(3 steps) Example: Biscuits, Cookies Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

MANUAL TRAY

DOWNLOAD TEMPLATE

053259DTM-M0031

Circle, ø 86 mm Example: Biscuits, Cookies, Macaron Shells Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template

MANUAL TRAY

DOWNLOAD TEMPLATE

053259DTM-M0502/503

27 Rectangles, 10 x 26 mm (M0502)
27 Rectangles, 8 x 25 mm (M0503) (3 mm Corner Radius)
Example: Pills, Mints This is a combination of two Trays Download NiceLabel Template Download Bartender Template Download PNG-file (any software) Download Swift Publisher Template
